前提条件

• 熟悉Python

相关介绍

• Python是一种跨平台的计算机程序设计语言。是一个高层次的结合了解释性、编译性、互动性和面向对象的脚本语言。最初被设计用于编写自动化脚本(shell)，随着版本的不断更新和语言新功能的添加，越多被用于独立的、大型项目的开发。
• PyTorch 是一个深度学习框架，封装好了很多网络和深度学习相关的工具方便我们调用，而不用我们一个个去单独写了。它分为 CPU 和 GPU 版本，其他框架还有 TensorFlow、Caffe 等。PyTorch 是由 Facebook 人工智能研究院（FAIR）基于 Torch 推出的，它是一个基于 Python 的可续计算包，提供两个高级功能：1、具有强大的 GPU 加速的张量计算（如 NumPy）；2、构建深度神经网络时的自动微分机制。
• YOLOv5是一种单阶段目标检测算法，该算法在YOLOv4的基础上添加了一些新的改进思路，使其速度与精度都得到了极大的性能提升。它是一个在COCO数据集上预训练的物体检测架构和模型系列，代表了Ultralytics对未来视觉AI方法的开源研究，其中包含了经过数千小时的研究和开发而形成的经验教训和最佳实践。
• Labelme是一款图像标注工具，由麻省理工(MIT)的计算机科学和人工智能实验室(CSAIL)研发。它是用Python和PyQT编写的，开源且免费。Labelme支持Windows、Linux和Mac等操作系统。
• 这款工具提供了直观的图形界面，允许用户在图像上标注多种类型的目标，例如矩形框、多边形、线条等，甚至包括更复杂的形状。标注结果以JSON格式保存，便于后续处理和分析。这些标注信息可以用于目标检测、图像分割、图像分类等任务。
• 总的来说，Labelme是一款强大且易用的图像标注工具，可以满足不同的图像处理需求。
• Labelme标注json文件是一种用于存储标注信息的文件格式，它包含了以下几个主要的字段：
  • version: Labelme的版本号，例如"4.5.6"。
  • flags: 一些全局的标志，例如是否是分割任务，是否有多边形，等等。
  • shapes: 一个列表，每个元素是一个字典，表示一个标注对象。每个字典包含了以下几个字段：
    • label: 标注对象的类别名称，例如"dog"。
    • points: 一个列表，每个元素是一个坐标对，表示标注对象的边界点，例如[[10, 20], [30, 40]]。
    • group_id: 标注对象的分组编号，用于表示属于同一组的对象，例如1。
    • shape_type: 标注对象的形状类型，例如"polygon"，“rectangle”，“circle”，等等。
    • flags: 一些针对该标注对象的标志，例如是否是难例，是否被遮挡，等等。
  • lineColor: 标注对象的边界线颜色，例如[0, 255, 0, 128]。
  • fillColor: 标注对象的填充颜色，例如[255, 0, 0, 128]。
  • imagePath: 图像文件的相对路径，例如"img_001.jpg"。
  • imageData: 图像文件的二进制数据，经过base64编码后的字符串，例如"iVBORw0KGgoAAAANSUhEUgAA…"。
  • imageHeight: 图像的高度，例如600。
  • imageWidth: 图像的宽度，例如800。

以下是一个Labelme标注json文件的示例：

{
  "version": "4.5.6",
  "flags": {},
  "shapes": [
    {
      "label": "dog",
      "points": [
        [
          121.0,
          233.0
        ],
        [
          223.0,
          232.0
        ],
        [
          246.0,
          334.0
        ],
        [
          121.0,
          337.0
        ]
      ],
      "group_id": null,
      "shape_type": "polygon",
      "flags": {}
    }
  ],
  "lineColor": [
    0,
    255,
    0,
    128
  ],
  "fillColor": [
    255,
    0,
    0,
    128
  ],
  "imagePath": "img_001.jpg",
  "imageData": "iVBORw0KGgoAAAANSUhEUgAA...",
  "imageHeight": 600,
  "imageWidth": 800
}

实验环境

• Python 3.x （面向对象的高级语言）
• albumentations==1.3.1
• opencv-python==4.12.0.88

Python将Labelme实例分割数据集和JSON标注文件生成黑白掩码

• png：图片数据集。
• json：Labelme标注文件。

{
  "version": "5.5.0",
  "flags": {},
  "shapes": [
    {
      "label": "2",
      "points": [
        [
          328.401273,
          330.659604
        ],
        [
          328.401273,
          335.183068
        ],
        [
          327.49687500000005,
          336.087664
        ],
        [
          327.49687500000005,
          336.99226
        ],
        [
          326.592477,
          337.896856
        ],
        [
          326.592477,
          338.80145200000004
        ],
        [
          325.6875,
          339.706048
        ],
        [
          325.6875,
          341.515724
        ],
        [
          324.782523,
          342.42032
        ],
        [
          324.782523,
          344.229512
        ],
        [
          323.87812499999995,
          345.13459200000005
        ],
        [
          323.87812499999995,
          346.03918799999997
        ],
        [
          322.06875,
          347.84837999999996
        ],
        [
          322.06875,
          348.752976
        ],
        [
          321.16435199999995,
          349.658056
        ],
        [
          321.16435199999995,
          350.562652
        ],
        [
          320.259375,
          351.46724800000004
        ],
        [
          320.259375,
          352.371844
        ],
        [
          318.45000000000005,
          354.18152
        ],
        [
          318.45000000000005,
          355.086116
        ],
        [
          317.545602,
          355.99071200000003
        ],
        [
          317.545602,
          357.799904
        ],
        [
          316.640625,
          358.7045
        ],
        [
          316.640625,
          359.60958
        ],
        [
          315.735648,
          360.51417599999996
        ],
        [
          315.735648,
          361.418772
        ],
        [
          314.83124999999995,
          362.323368
        ],
        [
          314.83124999999995,
          363.227964
        ],
        [
          313.926273,
          364.13256
        ],
        [
          313.926273,
          365.942236
        ],
        [
          312.11689800000005,
          367.751428
        ],
        [
          309.40312500000005,
          367.751428
        ],
        [
          309.40312500000005,
          427.461056
        ],
        [
          312.11689800000005,
          427.461056
        ],
        [
          313.021875,
          428.365652
        ],
        [
          313.926273,
          428.365652
        ],
        [
          314.83124999999995,
          429.270248
        ],
        [
          317.545602,
          429.270248
        ],
        [
          318.45000000000005,
          428.365652
        ],
        [
          319.354398,
          428.365652
        ],
        [
          321.16435199999995,
          426.55645999999996
        ],
        [
          322.06875,
          426.55645999999996
        ],
        [
          323.87812499999995,
          424.746784
        ],
        [
          325.6875,
          424.746784
        ],
        [
          326.592477,
          423.842188
        ],
        [
          344.686227,
          423.842188
        ],
        [
          345.59062500000005,
          424.746784
        ],
        [
          346.495023,
          423.842188
        ],
        [
          378.15937499999995,
          423.842188
        ],
        [
          379.063773,
          424.746784
        ],
        [
          393.53935199999995,
          424.746784
        ],
        [
          394.44375,
          425.65138
        ],
        [
          403.490625,
          425.65138
        ],
        [
          404.395023,
          426.55645999999996
        ],
        [
          407.109375,
          426.55645999999996
        ],
        [
          408.014352,
          427.461056
        ],
        [
          408.91875000000005,
          427.461056
        ],
        [
          409.823148,
          428.365652
        ],
        [
          410.728125,
          428.365652
        ],
        [
          411.63310199999995,
          429.270248
        ],
        [
          412.5375,
          429.270248
        ],
        [
          413.441898,
          430.174844
        ],
        [
          418.870023,
          430.174844
        ],
        [
          419.775,
          429.270248
        ],
        [
          420.67939800000005,
          429.270248
        ],
        [
          422.488773,
          427.461056
        ],
        [
          422.488773,
          426.55645999999996
        ],
        [
          423.39374999999995,
          425.65138
        ],
        [
          423.39374999999995,
          424.746784
        ],
        [
          424.298148,
          423.842188
        ],
        [
          424.298148,
          422.937592
        ],
        [
          425.203125,
          422.032996
        ],
        [
          425.203125,
          421.12791599999997
        ],
        [
          426.108102,
          420.22332
        ],
        [
          426.108102,
          417.50953200000004
        ],
        [
          427.01250000000005,
          416.604936
        ],
        [
          427.01250000000005,
          414.79526
        ],
        [
          427.916898,
          413.89066399999996
        ],
        [
          427.916898,
          412.081472
        ],
        [
          428.821875,
          411.176392
        ],
        [
          428.821875,
          410.271796
        ],
        [
          429.72685199999995,
          409.3672
        ],
        [
          429.72685199999995,
          405.748332
        ],
        [
          430.63125,
          404.84373600000004
        ],
        [
          430.63125,
          393.987616
        ],
        [
          429.72685199999995,
          393.08302
        ],
        [
          429.72685199999995,
          388.559556
        ],
        [
          428.821875,
          387.654476
        ],
        [
          428.821875,
          383.131012
        ],
        [
          427.916898,
          382.226416
        ],
        [
          427.916898,
          379.51262799999995
        ],
        [
          427.01250000000005,
          378.60803200000004
        ],
        [
          427.01250000000005,
          376.798356
        ],
        [
          426.108102,
          375.89376
        ],
        [
          426.108102,
          374.084568
        ],
        [
          425.203125,
          373.17948800000005
        ],
        [
          425.203125,
          372.274892
        ],
        [
          424.298148,
          371.370296
        ],
        [
          424.298148,
          370.4657
        ],
        [
          423.39374999999995,
          369.561104
        ],
        [
          423.39374999999995,
          367.751428
        ],
        [
          421.584375,
          365.942236
        ],
        [
          421.584375,
          365.03764
        ],
        [
          419.775,
          363.227964
        ],
        [
          419.775,
          362.323368
        ],
        [
          417.96562500000005,
          360.51417599999996
        ],
        [
          417.96562500000005,
          359.60958
        ],
        [
          416.15625,
          357.799904
        ],
        [
          416.15625,
          356.895308
        ],
        [
          415.251273,
          355.99071200000003
        ],
        [
          415.251273,
          355.086116
        ],
        [
          412.5375,
          352.371844
        ],
        [
          412.5375,
          351.46724800000004
        ],
        [
          411.63310199999995,
          350.562652
        ],
        [
          411.63310199999995,
          349.658056
        ],
        [
          408.91875000000005,
          346.943784
        ],
        [
          408.91875000000005,
          346.03918799999997
        ],
        [
          406.204398,
          343.32491600000003
        ],
        [
          406.204398,
          342.42032
        ],
        [
          399.87187500000005,
          336.087664
        ],
        [
          398.967477,
          336.087664
        ],
        [
          398.0625,
          335.183068
        ],
        [
          396.25312499999995,
          335.183068
        ],
        [
          394.44375,
          333.37339199999997
        ],
        [
          394.44375,
          330.659604
        ]
      ],
      "group_id": null,
      "description": null,
      "shape_type": "polygon",
      "flags": {},
      "mask": null
    },
    {
      "label": "2",
      "points": [
        [
          88.65937500000001,
          312.565748
        ],
        [
          88.65937500000001,
          315.279536
        ],
        [
          84.135648,
          319.803
        ],
        [
          84.135648,
          320.70759599999997
        ],
        [
          83.23124999999999,
          321.612676
        ],
        [
          83.23124999999999,
          322.517272
        ],
        [
          82.326273,
          323.421868
        ],
        [
          82.326273,
          324.326464
        ],
        [
          81.421875,
          325.23106
        ],
        [
          81.421875,
          326.13613999999995
        ],
        [
          80.517477,
          327.040736
        ],
        [
          80.517477,
          328.849928
        ],
        [
          79.61250000000001,
          329.754524
        ],
        [
          79.61250000000001,
          330.659604
        ],
        [
          78.707523,
          331.5642
        ],
        [
          78.707523,
          333.37339199999997
        ],
        [
          77.803125,
          334.277988
        ],
        [
          77.803125,
          336.087664
        ],
        [
          76.898148,
          336.99226
        ],
        [
          76.898148,
          337.896856
        ],
        [
          75.99375,
          338.80145200000004
        ],
        [
          75.99375,
          340.611128
        ],
        [
          75.088773,
          341.515724
        ],
        [
          75.088773,
          343.32491600000003
        ],
        [
          74.18437499999999,
          344.229512
        ],
        [
          74.18437499999999,
          346.03918799999997
        ],
        [
          73.279398,
          346.943784
        ],
        [
          73.279398,
          348.752976
        ],
        [
          72.375,
          349.658056
        ],
        [
          72.375,
          351.46724800000004
        ],
        [
          71.470602,
          352.371844
        ],
        [
          71.470602,
          353.27644
        ],
        [
          70.565625,
          354.18152
        ],
        [
          70.565625,
          355.086116
        ],
        [
          69.660648,
          355.99071200000003
        ],
        [
          66.946875,
          355.99071200000003
        ],
        [
          66.946875,
          409.3672
        ],
        [
          69.660648,
          409.3672
        ],
        [
          71.470602,
          411.176392
        ],
        [
          71.470602,
          412.081472
        ],
        [
          74.18437499999999,
          414.79526
        ],
        [
          74.18437499999999,
          415.699856
        ],
        [
          77.803125,
          419.31872400000003
        ],
        [
          78.707523,
          419.31872400000003
        ],
        [
          84.135648,
          424.746784
        ],
        [
          85.040625,
          424.746784
        ],
        [
          88.65937500000001,
          428.365652
        ],
        [
          90.46875,
          428.365652
        ],
        [
          91.373148,
          429.270248
        ],
        [
          95.896875,
          429.270248
        ],
        [
          96.801273,
          428.365652
        ],
        [
          97.70625000000001,
          428.365652
        ],
        [
          99.515625,
          426.55645999999996
        ],
        [
          100.420023,
          426.55645999999996
        ],
        [
          104.039352,
          422.937592
        ],
        [
          104.94375,
          422.937592
        ],
        [
          105.848148,
          422.032996
        ],
        [
          132.084375,
          422.032996
        ],
        [
          132.988773,
          422.937592
        ],
        [
          144.75,
          422.937592
        ],
        [
          145.65439800000001,
          423.842188
        ],
        [
          151.08252299999998,
          423.842188
        ],
        [
          151.9875,
          424.746784
        ],
        [
          158.320602,
          424.746784
        ],
        [
          159.22500000000002,
          425.65138
        ],
        [
          166.46249999999998,
          425.65138
        ],
        [
          167.366898,
          426.55645999999996
        ],
        [
          170.08125,
          426.55645999999996
        ],
        [
          170.985648,
          427.461056
        ],
        [
          172.79502300000001,
          427.461056
        ],
        [
          173.7,
          428.365652
        ],
        [
          174.60497700000002,
          428.365652
        ],
        [
          175.50937499999998,
          429.270248
        ],
        [
          176.414352,
          429.270248
        ],
        [
          177.31875000000002,
          430.174844
        ],
        [
          178.22314799999998,
          430.174844
        ],
        [
          179.128125,
          431.079924
        ],
        [
          180.032523,
          431.079924
        ],
        [
          181.84189800000001,
          432.889116
        ],
        [
          183.65185200000002,
          432.889116
        ],
        [
          184.55624999999998,
          433.79371199999997
        ],
        [
          189.079398,
          433.79371199999997
        ],
        [
          190.88877300000001,
          431.98452000000003
        ],
        [
          190.88877300000001,
          431.079924
        ],
        [
          192.69872700000002,
          429.270248
        ],
        [
          192.69872700000002,
          428.365652
        ],
        [
          193.60312499999998,
          427.461056
        ],
        [
          193.60312499999998,
          426.55645999999996
        ],
        [
          194.508102,
          425.65138
        ],
        [
          194.508102,
          424.746784
        ],
        [
          195.41250000000002,
          423.842188
        ],
        [
          195.41250000000002,
          422.937592
        ],
        [
          196.31689799999998,
          422.032996
        ],
        [
          196.31689799999998,
          421.12791599999997
        ],
        [
          199.03125,
          418.414128
        ],
        [
          199.03125,
          417.50953200000004
        ],
        [
          201.74560200000002,
          414.79526
        ],
        [
          202.64999999999998,
          414.79526
        ],
        [
          204.45937500000002,
          412.986068
        ],
        [
          205.36377299999998,
          412.986068
        ],
        [
          206.26875,
          412.081472
        ],
        [
          208.98252300000001,
          412.081472
        ],
        [
          209.8875,
          411.176392
        ],
        [
          220.74374999999998,
          411.176392
        ],
        [
          221.648148,
          412.081472
        ],
        [
          222.55312500000002,
          411.176392
        ],
        [
          223.45752299999998,
          411.176392
        ],
        [
          224.3625,
          410.271796
        ],
        [
          225.266898,
          410.271796
        ],
        [
          227.07627300000001,
          408.462604
        ],
        [
          227.07627300000001,
          407.558008
        ],
        [
          227.98125,
          406.65292800000003
        ],
        [
          227.98125,
          403.93914
        ],
        [
          228.88622700000002,
          403.034544
        ],
        [
          228.88622700000002,
          389.464152
        ],
        [
          229.79062499999998,
          388.559556
        ],
        [
          232.50439799999998,
          388.559556
        ],
        [
          232.50439799999998,
          384.940688
        ],
        [
          229.79062499999998,
          384.940688
        ],
        [
          228.88622700000002,
          384.036092
        ],
        [
          228.88622700000002,
          382.226416
        ],
        [
          227.98125,
          381.32182
        ],
        [
          227.98125,
          378.60803200000004
        ],
        [
          227.07627300000001,
          377.702952
        ],
        [
          227.07627300000001,
          375.89376
        ],
        [
          225.266898,
          374.084568
        ],
        [
          225.266898,
          372.274892
        ],
        [
          224.3625,
          371.370296
        ],
        [
          224.3625,
          369.561104
        ],
        [
          223.45752299999998,
          368.656024
        ],
        [
          223.45752299999998,
          367.751428
        ],
        [
          222.55312500000002,
          366.846832
        ],
        [
          222.55312500000002,
          365.942236
        ],
        [
          221.648148,
          365.03764
        ],
        [
          221.648148,
          363.227964
        ],
        [
          220.74374999999998,
          362.323368
        ],
        [
          220.74374999999998,
          360.51417599999996
        ],
        [
          219.83935200000002,
          359.60958
        ],
        [
          219.83935200000002,
          357.799904
        ],
        [
          218.934375,
          356.895308
        ],
        [
          218.934375,
          355.086116
        ],
        [
          218.02939800000001,
          354.18152
        ],
        [
          218.02939800000001,
          353.27644
        ],
        [
          217.125,
          352.371844
        ],
        [
          217.125,
          351.46724800000004
        ],
        [
          216.220023,
          350.562652
        ],
        [
          216.220023,
          349.658056
        ],
        [
          214.41064799999998,
          347.84837999999996
        ],
        [
          214.41064799999998,
          346.943784
        ],
        [
          213.50625000000002,
          346.03918799999997
        ],
        [
          213.50625000000002,
          345.13459200000005
        ],
        [
          212.601852,
          344.229512
        ],
        [
          212.601852,
          343.32491600000003
        ],
        [
          211.69687499999998,
          342.42032
        ],
        [
          211.69687499999998,
          341.515724
        ],
        [
          210.79247700000002,
          340.611128
        ],
        [
          210.79247700000002,
          338.80145200000004
        ],
        [
          209.8875,
          337.896856
        ],
        [
          209.8875,
          336.99226
        ],
        [
          208.98252300000001,
          336.087664
        ],
        [
          208.98252300000001,
          334.277988
        ],
        [
          208.078125,
          333.37339199999997
        ],
        [
          208.078125,
          331.5642
        ],
        [
          207.173148,
          330.659604
        ],
        [
          207.173148,
          329.754524
        ],
        [
          205.36377299999998,
          327.945332
        ],
        [
          205.36377299999998,
          327.040736
        ],
        [
          203.554398,
          325.23106
        ],
        [
          202.64999999999998,
          325.23106
        ],
        [
          199.93564800000001,
          322.517272
        ],
        [
          199.03125,
          322.517272
        ],
        [
          198.126273,
          321.612676
        ],
        [
          197.221875,
          321.612676
        ],
        [
          196.31689799999998,
          320.70759599999997
        ],
        [
          194.508102,
          320.70759599999997
        ],
        [
          193.60312499999998,
          319.803
        ],
        [
          191.79375,
          319.803
        ],
        [
          190.88877300000001,
          318.898404
        ],
        [
          189.079398,
          318.898404
        ],
        [
          188.175,
          317.993808
        ],
        [
          185.460648,
          317.993808
        ],
        [
          184.55624999999998,
          317.08921200000003
        ],
        [
          181.84189800000001,
          317.08921200000003
        ],
        [
          180.9375,
          316.184616
        ],
        [
          180.032523,
          316.184616
        ],
        [
          179.128125,
          315.279536
        ],
        [
          179.128125,
          312.565748
        ]
      ],
      "group_id": null,
      "description": null,
      "shape_type": "polygon",
      "flags": {},
      "mask": null
    },
    {
      "label": "2",
      "points": [
        [
          208.078125,
          330.659604
        ],
        [
          208.078125,
          340.611128
        ],
        [
          210.79247700000002,
          340.611128
        ],
        [
          213.50625000000002,
          343.32491600000003
        ],
        [
          213.50625000000002,
          344.229512
        ],
        [
          217.125,
          347.84837999999996
        ],
        [
          217.125,
          348.752976
        ],
        [
          218.02939800000001,
          349.658056
        ],
        [
          218.02939800000001,
          350.562652
        ],
        [
          218.934375,
          351.46724800000004
        ],
        [
          218.934375,
          352.371844
        ],
        [
          219.83935200000002,
          353.27644
        ],
        [
          219.83935200000002,
          355.086116
        ],
        [
          220.74374999999998,
          355.99071200000003
        ],
        [
          220.74374999999998,
          357.799904
        ],
        [
          221.648148,
          358.7045
        ],
        [
          221.648148,
          361.418772
        ],
        [
          222.55312500000002,
          362.323368
        ],
        [
          222.55312500000002,
          364.13256
        ],
        [
          223.45752299999998,
          365.03764
        ],
        [
          223.45752299999998,
          365.942236
        ],
        [
          224.3625,
          366.846832
        ],
        [
          224.3625,
          367.751428
        ],
        [
          225.266898,
          368.656024
        ],
        [
          225.266898,
          370.4657
        ],
        [
          226.171875,
          371.370296
        ],
        [
          226.171875,
          373.17948800000005
        ],
        [
          229.79062499999998,
          376.798356
        ],
        [
          229.79062499999998,
          377.702952
        ],
        [
          231.60000000000002,
          377.702952
        ],
        [
          232.50439799999998,
          378.60803200000004
        ],
        [
          236.12314800000001,
          378.60803200000004
        ],
        [
          237.028125,
          379.51262799999995
        ],
        [
          239.741898,
          379.51262799999995
        ],
        [
          240.64687500000002,
          378.60803200000004
        ],
        [
          242.45625,
          378.60803200000004
        ],
        [
          243.360648,
          377.702952
        ],
        [
          244.265625,
          377.702952
        ],
        [
          247.88437499999998,
          374.084568
        ],
        [
          247.88437499999998,
          373.17948800000005
        ],
        [
          248.789352,
          372.274892
        ],
        [
          248.789352,
          371.370296
        ],
        [
          249.69375000000002,
          370.4657
        ],
        [
          249.69375000000002,
          367.751428
        ],
        [
          250.59814799999998,
          366.846832
        ],
        [
          250.59814799999998,
          361.418772
        ],
        [
          249.69375000000002,
          360.51417599999996
        ],
        [
          249.69375000000002,
          355.086116
        ],
        [
          248.789352,
          354.18152
        ],
        [
          248.789352,
          348.752976
        ],
        [
          247.88437499999998,
          347.84837999999996
        ],
        [
          247.88437499999998,
          345.13459200000005
        ],
        [
          246.97997700000002,
          344.229512
        ],
        [
          246.97997700000002,
          341.515724
        ],
        [
          245.17002300000001,
          339.706048
        ],
        [
          245.17002300000001,
          337.896856
        ],
        [
          243.360648,
          336.087664
        ],
        [
          242.45625,
          336.087664
        ],
        [
          240.64687500000002,
          334.277988
        ],
        [
          240.64687500000002,
          330.659604
        ]
      ],
      "group_id": null,
      "description": null,
      "shape_type": "polygon",
      "flags": {},
      "mask": null
    },
    {
      "label": "7",
      "points": [
        [
          229.79062499999998,
          316.184616
        ],
        [
          229.79062499999998,
          331.5642
        ],
        [
          234.313773,
          331.5642
        ],
        [
          235.21875,
          332.468796
        ],
        [
          237.93310200000002,
          332.468796
        ],
        [
          238.83749999999998,
          333.37339199999997
        ],
        [
          239.741898,
          333.37339199999997
        ],
        [
          241.55127299999998,
          335.183068
        ],
        [
          242.45625,
          335.183068
        ],
        [
          245.17002300000001,
          337.896856
        ],
        [
          245.17002300000001,
          338.80145200000004
        ],
        [
          246.075,
          339.706048
        ],
        [
          246.075,
          340.611128
        ],
        [
          246.97997700000002,
          341.515724
        ],
        [
          246.97997700000002,
          344.229512
        ],
        [
          247.88437499999998,
          345.13459200000005
        ],
        [
          247.88437499999998,
          347.84837999999996
        ],
        [
          248.789352,
          348.752976
        ],
        [
          248.789352,
          354.18152
        ],
        [
          249.69375000000002,
          355.086116
        ],
        [
          249.69375000000002,
          359.60958
        ],
        [
          250.59814799999998,
          360.51417599999996
        ],
        [
          250.59814799999998,
          363.227964
        ],
        [
          251.503125,
          364.13256
        ],
        [
          251.503125,
          365.03764
        ],
        [
          254.21689800000001,
          367.751428
        ],
        [
          276.834375,
          367.751428
        ],
        [
          277.739352,
          368.656024
        ],
        [
          279.548148,
          368.656024
        ],
        [
          280.453125,
          369.561104
        ],
        [
          282.2625,
          369.561104
        ],
        [
          283.166898,
          370.4657
        ],
        [
          283.166898,
          373.17948800000005
        ],
        [
          283.166898,
          369.561104
        ],
        [
          284.071875,
          368.656024
        ],
        [
          284.071875,
          367.751428
        ],
        [
          284.976852,
          366.846832
        ],
        [
          284.976852,
          333.37339199999997
        ],
        [
          284.071875,
          332.468796
        ],
        [
          284.071875,
          329.754524
        ],
        [
          283.166898,
          328.849928
        ],
        [
          283.166898,
          327.040736
        ],
        [
          282.2625,
          326.13613999999995
        ],
        [
          282.2625,
          324.326464
        ],
        [
          281.358102,
          323.421868
        ],
        [
          281.358102,
          322.517272
        ],
        [
          279.548148,
          320.70759599999997
        ],
        [
          279.548148,
          319.803
        ],
        [
          278.64375,
          318.898404
        ],
        [
          278.64375,
          316.184616
        ]
      ],
      "group_id": null,
      "description": null,
      "shape_type": "polygon",
      "flags": {},
      "mask": null
    },
    {
      "label": "2",
      "points": [
        [
          310.307523,
          334.277988
        ],
        [
          310.307523,
          337.896856
        ],
        [
          309.40312500000005,
          338.80145200000004
        ],
        [
          309.40312500000005,
          339.706048
        ],
        [
          307.59375,
          341.515724
        ],
        [
          307.59375,
          342.42032
        ],
        [
          306.688773,
          343.32491600000003
        ],
        [
          306.688773,
          344.229512
        ],
        [
          304.879398,
          346.03918799999997
        ],
        [
          302.165625,
          346.03918799999997
        ],
        [
          302.165625,
          359.60958
        ],
        [
          305.78437499999995,
          359.60958
        ],
        [
          306.688773,
          360.51417599999996
        ],
        [
          310.307523,
          360.51417599999996
        ],
        [
          311.2125,
          361.418772
        ],
        [
          314.83124999999995,
          361.418772
        ],
        [
          315.735648,
          360.51417599999996
        ],
        [
          316.640625,
          360.51417599999996
        ],
        [
          317.545602,
          359.60958
        ],
        [
          317.545602,
          358.7045
        ],
        [
          318.45000000000005,
          357.799904
        ],
        [
          318.45000000000005,
          356.895308
        ],
        [
          319.354398,
          355.99071200000003
        ],
        [
          319.354398,
          355.086116
        ],
        [
          320.259375,
          354.18152
        ],
        [
          320.259375,
          353.27644
        ],
        [
          321.16435199999995,
          352.371844
        ],
        [
          321.16435199999995,
          350.562652
        ],
        [
          322.06875,
          349.658056
        ],
        [
          322.06875,
          348.752976
        ],
        [
          322.973148,
          347.84837999999996
        ],
        [
          322.973148,
          346.943784
        ],
        [
          323.87812499999995,
          346.03918799999997
        ],
        [
          323.87812499999995,
          345.13459200000005
        ],
        [
          324.782523,
          344.229512
        ],
        [
          324.782523,
          343.32491600000003
        ],
        [
          325.6875,
          342.42032
        ],
        [
          325.6875,
          341.515724
        ],
        [
          327.49687500000005,
          339.706048
        ],
        [
          330.21064800000005,
          339.706048
        ],
        [
          330.21064800000005,
          334.277988
        ]
      ],
      "group_id": null,
      "description": null,
      "shape_type": "polygon",
      "flags": {},
      "mask": null
    },
    {
      "label": "2",
      "points": [
        [
          284.071875,
          334.277988
        ],
        [
          284.071875,
          351.46724800000004
        ],
        [
          293.11875,
          351.46724800000004
        ],
        [
          293.11875,
          348.752976
        ],
        [
          294.02314800000005,
          347.84837999999996
        ],
        [
          296.73749999999995,
          347.84837999999996
        ],
        [
          297.641898,
          346.943784
        ],
        [
          302.165625,
          346.943784
        ],
        [
          303.07060199999995,
          346.03918799999997
        ],
        [
          303.975,
          346.03918799999997
        ],
        [
          303.975,
          345.13459200000005
        ],
        [
          304.879398,
          344.229512
        ],
        [
          308.498727,
          344.229512
        ],
        [
          308.498727,
          334.277988
        ]
      ],
      "group_id": null,
      "description": null,
      "shape_type": "polygon",
      "flags": {},
      "mask": null
    }
  ],
  "imagePath": "1.png",
  "imageData": null,
  "imageHeight": 484,
  "imageWidth": 579
}

代码实现

import os
import json
import numpy as np
from PIL import Image
from tqdm import tqdm

def create_binary_mask_from_labelme(json_path, output_path, image_shape, target_classes):
    """
    从 labelme 的 json 文件生成黑白 mask 图像。

    参数:
        json_path (str): json 文件路径
        output_path (str): mask 输出路径
        image_shape (tuple): (height, width)
        target_classes (list): 需要生成掩码的目标类别列表
    """
    with open(json_path, 'r', encoding='utf-8') as f:
        data = json.load(f)

    height, width = image_shape
    mask = np.zeros((height, width), dtype=np.uint8)

    for shape in data['shapes']:
        label = shape['label']
        if label not in target_classes:
            continue

        points = shape['points']
        polygon = [(int(p[0]), int(p[1])) for p in points]

        # 使用 PIL 的 ImageDraw 绘制多边形区域
        from PIL import ImageDraw

        img_mask = Image.new('L', (width, height), 0)
        ImageDraw.Draw(img_mask).polygon(polygon, outline=255, fill=255)
        mask += np.array(img_mask)

    mask_img = Image.fromarray(mask)
    mask_img.save(output_path)

def convert_labelme_to_binary_masks(label_dir, image_dir, mask_dir, target_classes):
    """
    批量将 labelme json 转换为黑白 mask 图像。

    参数:
        label_dir (str): json 文件目录
        image_dir (str): 原始图像目录（用于获取尺寸）
        mask_dir (str): 输出 mask 目录
        target_classes (list): 需要生成掩码的目标类别列表
    """
    os.makedirs(mask_dir, exist_ok=True)

    json_files = [f for f in os.listdir(label_dir) if f.endswith('.json')]

    for json_file in tqdm(json_files, desc="生成黑白 mask"):
        base_name = os.path.splitext(json_file)[0]
        json_path = os.path.join(label_dir, json_file)

        # 获取原始图像尺寸
        image_path = os.path.join(image_dir, base_name + ".jpg")
        if not os.path.exists(image_path):
            image_path = os.path.join(image_dir, base_name + ".png")
        if not os.path.exists(image_path):
            raise FileNotFoundError(f"找不到与 {json_file} 对应的图像文件")

        with Image.open(image_path) as img:
            image_shape = (img.height, img.width)

        output_path = os.path.join(mask_dir, base_name + ".png")

        create_binary_mask_from_labelme(json_path, output_path, image_shape, target_classes)

if __name__ == "__main__":
    # 修改以下路径和类别名称
    label_dir = r"segment"
    image_dir = r"segment"
    mask_dir = r"segment\masks"

    # 替换为你自己的类别列表
    # class_names = ['background', 'person', 'car', 'dog']  # 第一个是 background（可选）
    class_names = ['0', '1', '2', '3', '4', '5', '6', '7', '8', '9',
                '10', '11', '12', '13', '14', '15', '16', '17', '18', '19',
                '20', '21', '22', '23', '24', '25', '26', '27', '28', '29',
                '30', '31', '32', '33', '34', '35', '36', '37', '38', '39',
                '40', '41', '42', '43', '44', '45', '46', '47', '48', '49',
                '50', '51', '52', '53', '54', '55', '56', '57', '58', '59',
                '60', '61', '62', '63', '64', '65', '66', '67', '68', '69',
                '70', '71', '72', '73', '74', '75', '76', '77', '78', '79']  # 标签类别名

    convert_labelme_to_binary_masks(label_dir, image_dir, mask_dir, class_names)

输出结果

• 由于本人水平有限，难免出现错漏，敬请批评改正。
• 更多精彩内容，可点击进入Python日常小操作专栏、OpenCV-Python小应用专栏、YOLO系列专栏、自然语言处理专栏、人工智能混合编程实践专栏或我的个人主页查看
• 人工智能混合编程实践：C++调用Python ONNX进行YOLOv8推理
• 人工智能混合编程实践：C++调用封装好的DLL进行YOLOv8实例分割
• 人工智能混合编程实践：C++调用Python ONNX进行图像超分重建
• 人工智能混合编程实践：C++调用Python AgentOCR进行文本识别
• 通过计算实例简单地理解PatchCore异常检测
• Python将YOLO格式实例分割数据集转换为COCO格式实例分割数据集
• YOLOv8 Ultralytics：使用Ultralytics框架训练RT-DETR实时目标检测模型
• 基于DETR的人脸伪装检测
• YOLOv7训练自己的数据集（口罩检测）
• YOLOv8训练自己的数据集（足球检测）
• YOLOv5：TensorRT加速YOLOv5模型推理
• YOLOv5：IoU、GIoU、DIoU、CIoU、EIoU
• 玩转Jetson Nano（五）：TensorRT加速YOLOv5目标检测
• YOLOv5：添加SE、CBAM、CoordAtt、ECA注意力机制
• YOLOv5：yolov5s.yaml配置文件解读、增加小目标检测层
• Python将COCO格式实例分割数据集转换为YOLO格式实例分割数据集
• YOLOv5：使用7.0版本训练自己的实例分割模型（车辆、行人、路标、车道线等实例分割）
• 使用Kaggle GPU资源免费体验Stable Diffusion开源项目
