【python】OpenCV—Merge Image

1、np.hstack / np.vstack

利用 numpy 的 hstack 和 vstack，对图片进行拼接

import cv2
import numpy as np

h, w = 256,256
img1 = cv2.resize(cv2.imread("1.jpg"), (w, h))
img2 = cv2.resize(cv2.imread("2.png"), (w, h))

horizontal = np.hstack((img1, img2))
cv2.imwrite("horizontal.jpg", horizontal)

vertical = np.vstack((img1, img2))
cv2.imwrite("vertical.jpg", vertical)

输入图片

horizontal

vertical

2、Slice

学习来自 Python 图像合并：利用 OpenCV 的强大功能

图片 reszie 成同样大小，生成空白图，利用切片，给相应区域赋值

import cv2
import numpy as np

dimension = 256
canvas_dimension = 2 * dimension

img1 = cv2.resize(cv2.imread("1.png"), (dimension, dimension))
img2 = cv2.resize(cv2.imread("2.png"), (dimension, dimension))
img3 = cv2.resize(cv2.imread("3.png"), (dimension, dimension))
img4 = cv2.resize(cv2.imread("4.png"), (dimension, dimension))

canvas = np.zeros((canvas_dimension, canvas_dimension, 3), dtype=np.uint8)

canvas[0:dimension, 0:dimension] = img1
canvas[0:dimension, dimension:canvas_dimension] = img2
canvas
